A573/A573M Carbon Steel Plate

Product origin China
Delivery time 15-25 Working Days
Supply capacity Factory Direct Supply

ASTM A573/A573M grades include 58, 65 and 70. Steel plates are suitable for structural carbon-manganese-silicon steel plates with three tensile strength ranges. ASTM A573/A573M steel plates are mainly used to improve notch toughness at room temperature.

E-mail： admin@jinshugc.com

WhatsApp： 8615315750155

A573/A573M Carbon Steel Plate

A573/A573M

A573/A573M Carbon Steel Plate Description

A573/A573M steel plate has good impact resistance, small temperature deformation, good welding performance, micro-alloying, high purity, low carbon equivalent and strong resistance to hydrogen sulfur. Such plates are commonly used in petroleum, chemical industry, power stations, boilers and other industries to make reactors, heat exchangers, separators, spherical tanks, oil and gas tanks, liquefied gas tanks, nuclear reactor pressure shells, boiler drums, liquefied petroleum gas bottles, turbine casings and other equipment and components.

Product Parameters

Product Name	A573/A573M Carbon Steel Plate
Production Process	Hot Rolling, Cold Rolling
Material Standards	AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.
Width	100mm-3000mm
Length	1m-12m, or Customized Size
Thickness	0.1mm-400mm
Delivery Conditions	Rolling, Annealing, Quenching, Tempered or Standard
Surface Process	Ordinary, Wire Drawing, Laminated Film

Chemical Composition

A573	C max	Mn	P max	S max	Si
Grade 58	0.23	0.60-0.90	0.035	0.04	0.10-0.35
Grade 65	0.24-0.26	0.85-1.20	0.035	0.04	0.15-0.40
Grade 70	0.27-0.28	0.85-1.20	0.035	0.04	0.15-0.40
Grade 70	0.27-0.28	0.85-1.20	0.035	0.04	0.15-0.40
