A53 Seamless & Welded Carbon Steel Pipe
- China
- 15-25 Working Days
- Factory Direct Supply
A53 American standard seamless steel pipe is made of high-quality steel billets through hot rolling, cold drawing and other processes. The chemical composition and mechanical properties of this steel pipe comply with the requirements of American standard ASTM A53/A53M.
E-mail：
admin@jinshugc.com
WhatsApp：
8615315750155
A53 Seamless & Welded Carbon Steel Pipe
A53 American standard seamless steel pipe is made of high-quality steel billets through hot rolling, cold drawing and other processes. The chemical composition and mechanical properties of this steel pipe comply with the requirements of American standard ASTM A53/A53M.
A53 Seamless & Welded Carbon Steel Pipe Description
ASTM A53 seamless steel pipe has high strength, good toughness, good processing performance and welding performance. A53 American standard seamless steel pipes are available in a wide range of specifications, with a wide range of outer diameters and wall thicknesses. Because ASTM A53 seamless carbon steel pipe has excellent material properties and good processing performance, it is widely used in petroleum, chemical industry, electric power, machinery manufacturing and other fields. For example, in the petrochemical industry, ASTM A53 steel pipes can be used to transport high-temperature and high-pressure oil, natural gas and other media.
Product Parameters
Product Name | A53 Seamless & Welded Carbon Steel Pipe | |
Standard | EN/DIN/JIS/ASTM/BS/ASME/AISI etc. | |
Outer Diameter | Seamless: 1/4"-36" | Welding: 21.3mm-3620mm |
Round Tube: 1/2"-10" | Square Tube/Rectangular Tube: 15x15mm-400x600mm | |
Wall Thickness | Seamless: 1.25mm-50mm | Welding: 1.65mm-65mm |
Length | 3-12 meters, Support customization | |
Surface Process | Bright, Polished, Black | |
Other Services | Machining(cnc), Centerless Grinding(cg), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Small Machining, etc. | |
Chemical Composition
A53 | Grade | C | Mn | P | S | Cu | Ni | Cr | Mo | V |
Type S (Seamless) | A | 0.25 | 0.95 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 |
B | 0.3 | 1.2 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 | |
Type E (Resistance Welding) | A | 0.25 | 0.95 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 |
B | 0.3 | 1.2 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 | |
Type F (Furnace Welding) | A | 0.3 | 1.2 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 |
Mechanical Properties
A53 | Grade A | Grade B |
Tensile Strength Min. psi (MPa) | 48,000 (330) | 60,000 (415) |
Yield Strength Min. psi (MPa) | 30,000 (205) | 35,000 (240) |
Physical Performance
Density 20°C Kg/dm³ | Modulus of Elasticity Kn/² mm | Coefficient of Thermal Conductivity 20°C | Heat Capacity 20°C | Resistivity 20°C | |||
20 C° | 300 C° | 400 C° | 450 C° | ||||
7.85 | 210 | 192 | 184 | 179 | 51 | 461 | 0.20 |
Scope of Application
Construction: underground pipeline, underground water, hot water transmission, mechanical processing, bearing sleeve, processing machinery parts, etc.
Electrical: natural gas transmission, hydroelectric fluid pipelines, anti-static pipes for wind farms, etc.
